FMB003 GNSS OBD BL Tracker
72.00 €
Plug and play device with OEM parameters reading capability dedicated to OBD applications of next generation!
- Description
- Additional information
Description
FMB003 is an ultra-small plug and play device dedicated to OBD applications of next generation.
The main feature of FMB003 is its possibility to read OEM parameters (PIDs) via OBD port.
With this device, you will be able to read Real Odometer and Real Fuel Level data. What’s more, our device comes with the supported vehicle
s and data list, so no need to guess anymore – now you know what data you can read from a specific vehicle.
It is a perfect tracker for a wide range of use cases – including fleet management of light commercial vehicles, driver log-book, insurance telematics (UBI), car rental & leasing and more.
The device supports various BLE 4.0 sensors, beacons, hands-free headsets, firmware and configuration updates via Bluetooth, thus, expanding its already rich set of features.
FMB003 – setting a new standard in OBD tracking!
Additional information
| Manufacturer | Teltonika |
|---|---|
| MPN | FMB003 |
| Module Name | Teltonika TM2500 |
| Module Technology | GSM/GPRS/GNSS/BLUETOOTH |
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
| GNSS Receiver | 33 channel |
| Tracking sensitivity | -165 dBM |
| Accuracy | < 2.5m CEP |
| Hot start | < 1 s |
| Warm start | < 25 s |
| Cold start | < 35 s |
| Cellular Technology | GSM |
| 2G bands | Quad-band 850 / 900 / 1800 / 1900 MHz |
| Data transfer | GPRS Multi-Slot Class 12(up to 240 kbps) |
| Data support | SMS (text/data) |
| Supply voltage range | 10 – 30 V DC with overvoltage protection |
| Back-up battery | 3.7 V 45 mAh |
| Power consumption | At 12V < 5 mA (Ultra Deep Sleep), At 12V < 7 mA (Deep Sleep), At 12V < 7 mA (Online Sleep), At 12V < 8 mA (GPS Sleep), At 12V < 28 mA (nominal) |
| Bluetooth Specification | 4.0 + LE |
| Supported peripherals | Temperature and Humidity sensor, Headset, Inateck Barcode Scanner, Universal BLE sensors support |
| Interface Connection | OBDII Socket |
| GNSS antenna | Internal High Gain |
| Cellular antenna | Internal High Gain |
| USB | 2.0 Micro-USB |
| LED indication | 2 status LED lights |
| SIM | Nano-SIM |
| Memory | 128MB internal flash memory |
| Dimensions | 52.6 x 29.1 x 26 mm (L x W x H) |
| Operating temperature (without battery) | -40 °C to +85 °C |
| Storage temperature (without battery) | -40 °C to +85 °C |
| Operating humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP41 |
| Battery charge temperature | +10 °C to +45 °C |
| Battery discharge temperature | -20 °C to +60 °C |
| Battery storage temperature | -20 °C to +45 °C for 1 month, -20 °C to +35 °C for 6 months |
| Sensors | Accelerometer |
| Scenarios | Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
| Sleep modes | GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
| Configuration and firmware update | FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration) |
| SMS | Configuration, Events, Debug |
| GPRS commands | Configuration, Debug |
| Time Synchronization | GPS, NITZ, NTP |
| Fuel monitoring | OBD II |
| Ignition detection | Accelerometer, External Power Voltage, Engine RPM |
